UN5017 Fixed Focus Lens, 1/2.8" Sensor, 2.03mm, F2.2 Aperture Filter
UN5017 Fixed Focus Lens, 1/2.8" Sensor, 2.03mm, F2.2 Aperture
UN5017 fixed focus lens specially optimized for modern video conferencing, equipped with 1/2.8" sensor, supporting 4K ultra HD resolution, providing delicate and realistic images with excellent low-light performance. Its 117.2° ultra wide angle can easily cover the entire meeting space, ensuring every participant is clearly visible. TV distortion rate as low as -2.5%, image maintains natural proportions and edge sharpness, bringing more professional meeting experience. Compact optical design makes it easy to integrate into enterprise-level video conferencing and remote collaboration systems, ensuring high compatibility and stable performance.
$7.95
UN5017,1/2.8",14.75±0.3mm,2.2±5%,"22.49±0.3 （IR+CG=0.71MM）",3.0+±0.2（IR+CG=0.71mm）,∅6.8mm,117.2°±3°（∅=6.388mm）,110°±（∅=5.568mm）,74.6±3°（∅=3.132mm）,40%±5%（∅=6.388mm）,≥-2.5%,12±3°
4K Ultra HD resolution, presenting fine details
TV distortion as low as -2.5%, realistic images
117.2° ultra wide field of view, comprehensive coverage
1
If you have additional requirements for this product, you can Contact Usfor customized services
5M high-definition resolution
clear details, and accurate recognition
Large aperture
clear and bright image
Product Parameters
Part Number
UN5017
Sensor Type
1/2.8"
Focal Length
14.75±0.3mm
FNo.
2.2±5%
Total Length
"22.49±0.3 （IR+CG=0.71MM）"
Mechanical BFL
3.0+±0.2（IR+CG=0.71mm）
Max Image Circle
∅6.8mm
Optical FOV (D)
117.2°±3°（∅=6.388mm）
Optical FOV (H)
110°±（∅=5.568mm）
Optical FOV (V)
74.6±3°（∅=3.132mm）
Relative Illumination
40%±5%（∅=6.388mm）
TV Distortion
≥-2.5%
MAX Chief Ray Angle
12±3°
UN5017 fixed focus lens specially optimized for modern video conferencing, equipped with 1/2.8" sensor, supporting 4K ultra HD resolution, providing delicate and realistic images with excellent low-light performance. Its 117.2° ultra wide angle can easily cover the entire meeting space, ensuring every participant is clearly visible. TV distortion rate as low as -2.5%, image maintains natural proportions and edge sharpness, bringing more professional meeting experience. Compact optical design makes it easy to integrate into enterprise-level video conferencing and remote collaboration systems, ensuring high compatibility and stable performance.
