Union Optech
Our Manufacturing Capabilities
Our company has obtained the certifications of ISO 9001:2015, ISO 14001:2015 and ISO 45001:2018 management systems, and been accredited as a CNAS National Level Laboratory. We provide global customers with optical detection and reliability verification solutions that comply with international standards.
We are equipped with world-leading testing equipment, including the Trioptics ImageMaster Series MTF Test System, Compass Surface Profiler, Panasonic UA3P Ultra-High Precision 3D Measuring Machine and Zygo ZeGage Pro Non-Contact Profilometer. We fully support high-precision contact and non-contact measurements, with the contact measurement accuracy reaching up to 0.08 μm.
Our reliability testing capabilities cover a full range of items including thermal cycle, damp heat, thermal shock, vibration, IP waterproofing and salt spray tests, ensuring the high performance and durability of products under various harsh environmental conditions worldwide.
+Expand
ISO 9001
2015
ISO 14001
2015
ISO 45001
2018
Optical Testing Equipment
We are equipped with world-leading testing equipment
Contact and vision modes are used to test the mechanical dimensional accuracy of products and molds, including 3D (X, Y, Z) coordinates and partial geometric tolerances: ≥0.7 μm
Probe contact mode is used to test the surface profile and roughness dimensional accuracy of lenses such as aspheric, free-form, and cylindrical surfaces: ≥0.08 μm
Non-contact mode is used to test the surface profile dimensional accuracy of high-precision aspheric and spherical lenses: ≥0.08 μm
+Expand
Optical Test Gauge Head
Function
Device Image
MTF Tester
High-precision measurement
MTF Test
3d-optical-profiler
Three-dimensional measurement
MTF Tester
Contact surface profilometer
Optical Performance Evaluation (MTF, Distortion, RI, CRA)
Surface Profiler
Compact transfer function measuring instrument
Surface Profiling for Components Within ø6 mm
3d-optieal-profilet
3d-optieal-profilet
PV Value Measurement for Large-Aperture Spherical Surfaces
Non-Contact Surface Profiler
Flatness Measurement
Preferential treatment
Spherical Lens Measurement
Ultra-high precision three-dimensional measuring instrument
Surface Profiling
Ultra high precision CMM
Mechanical Measurement
3D Coordinate Measuring Machine
CMI 3
Mechanical Measurement
2.5D Image Measuring Instrument
Mechanical Measurement
High-precision roundness measuring instrument
Roundness and Concentricity Measurement
Reliability Test Capability
CNAS-Accredited Laboratory
Environmental testing
Waterproof testing
Optical analysis testing
Mechanical testing
Programmable Constant Temperature and Humidity Chamber
Temperature Cycling Machine
Thermal Shock Testing Machine
Waterproof Testing Machine
Electromagnetic Vibration Testing Machine
Salt Fog Test Equipment
Complex System Integration Test Capability
SFR Auto Actual Shooting
Automatic Alignment Equipment
Noise Detection Equipment
AF Fixed-point Detection Accuracy Equipment
Special Optical Assembly Equipment
MTF Testing Equipment
SFR Automatic Real-shot Equipment
Simulated Transportation Testing Machine
IPX9K Waterproof Testing Machine
Gravel Impact Testing Machine
Dust Test Chamber
Xenon Lamp Aging Machine
Thermal Shock Tester
Condensation Test Chamber
Salt Spray Test Equipment
